产品型号
| Pocket Spec | BT40/CAT40/DIN40/HSK63 | BT50/CAT50/DIN50/HSK100 | |||||||||||
| Tool Capacity | 40T/48T/60T | 40T/60T/120T | |||||||||||
| Max. Tool Diameter With Adjacent Pocket Full/Empty(mm) | 75/127 | 125/250 | |||||||||||
| Max. Tool Weight(kg) | 8 | 25 | |||||||||||
| Tool Change Time (sec/50hz) | 3（ATC） | 3（ATC） | |||||||||||
| Magazine Speed(sec/tool) | 0.65 | 0.85 | |||||||||||
| Tool Management Mode | Random | Random | |||||||||||
| Tool Change Selection | Hydraulic Rock and Gear Machanism | ||||||||||||
产品参数
暂无
